Part Number(s)
TouchPro PCAP (clear with anti-friction) – E343671
TouchPro PCAP (anti-glare) – E343872
Enclosure Color
Black
Touch Technology & Capacity
PCAP (TouchPro® Projected Capacitive) – 40 Touch with Palm Rejection and Touch Thru capability
Touch Thru
Supports up to 6mm glass/3mm plastic with up to 2 touches. Supports gloves up to 1.4mm
Touch Interface
USB
Diagonal Size
31.5” diagonal, Active matrix TFT LCD (LED)
On Screen Display
Accessible through switches on the OSD Control Remote accessory.
Controls (side): Menu, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Source, Touch, RTC, MDC, Touch Through
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
RTC Settings: The clock/time and the monitor ON/OFF schedule can be changed within this menu. Daylight Saving time is adjusted for automatically and will change the current time by one hour to accommodate daylight savings time.
See user manual for full details.
Aspect Ratio
16:9
Active Area (mm)
27.5″ x 15.47″ / 698.4 mm x 392.9 mm
Resolution
1920 x 1080 @ 60hz
Other Supported Resolutions
640×480 @ 60Hz
800×600 @ 56/60Hz
1024×768 @ 60Hz
1280×720 @ 60Hz
1280×800 @ 60Hz RB
1280×960 @ 60Hz
1280×1024 @ 60Hz
1366×768 @ 60Hz
1366×768 @ 60Hz RB
1440×900 @ 60Hz
1440×900 @ 60Hz RB
1680×1050 @ 60Hz
1680×1050 @ 60Hz RB
1920×1080 @ 60Hz
Viewing Angle
Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total
Number of Colors
8-bit (16.7 million)
Brightness (typical)
LCD panel: 500 nits
TouchPro PCAP: 425 nits
Response Time-total (typical)
8 msec
Contrast Ratio
3000:1
I/O Ports
HDMI 1.4 x2
USB 2.0 Type B (for Touch)
RJ45 (for optional OSD remote)
VGA
Video
2x HDCP-capable HDMI on Type A connector
Female DE-15 VGA connector
Input Video Horizontal Sync frequency range: 31.5 – 80 KHz
Input Video Vertical Sync (frame rate) frequency range: 47 – 63 KHz
Power
Input connector (power): IEC 60320-C14
Input signal specifications (power): 100-240VAC 50/60Hz
Maximum Operating Time
24 hours/day
Power Consumption (Typical)
ON (monitor + AC/DC adapter): 44.3 W
SLEEP (monitor + AC/DC adapter): 0.61 W
OFF (monitor + AC/DC adapter): 0.20 W
Dimensions
29.42″ x 17.82″ x 2.16″ / 747.3 mm x 452.7 mm x 55 mm
Shipping Box Dimensions
39.4″ x 12.05″ x 26.79″ / 1000 mm x 306 mm x 680 mm
Weight (Unpackaged)
24.17 lbs / 10.99 Kg
Weight (Packaged)
37.47 lbs / 17.03 Kg
Operating Temperature
Portrait/Landscape Mode: 0°C to 40°C / 32°F to 104°F
Tabletop Mode: 0° C to 35° C / 32°F to 95°F
Storage Temperature
Portrait/Landscape Mode: -20°C to 60°C / -4°F to 140°F
Tabletop Mode: -20° C to 60° C / -4° F to 140° F
Humidity
Operating: 20% to 80%
Storage: 10% to 90% (38.7°C max wet bulb temperature)
Sealability
Touchscreen sealed to bezel
Touchscreen sealed to LCD
MTBF
50,000 hours demonstrated
Warranty
3-year
Extended Service Options
4 year warranty coverage + AUR – Elo P/N: E740135
5 year warranty coverage + AUR – Elo P/N: E740330
Regulatory approvals and declarations
Argentina S-Mark
Australia RCM
Canada CUL, IC
China CCC
Europe CE
Japan VCCI
Korea KCC e-Standby
Mexico CoC
Russia EAC
Taiwan BSMI
United States UL, FCC
International CB
Mexico NOM
RoHS, China RoHS, WEEE
Energy Star 8.0
UL 60950 ball-drop compliant
IK07 impact compliant
CB (International safety) (IEC/EN60950-1+IEC/EN62368-1)
Mounting Options
VESA 400mm x 200mm
See dimensional drawings for details
Other Features
Ambient Light Sensor – changes panel color to match ambient light, Auto Wake
What’s in the Box
Quick Install Guide
HDMI 1.4 cable (Type A plug to Type A plug)
VGA cable (DB-15 male to DB-15 male)
USB cable (Type A plug to Type B plug)
RJ45 Wired OSD remote
Power cable, IEC 60320-C13 to NA plug
Power cable, IEC 60320-C13 to EU/KR plug
Power cable, IEC 60320-C13 to UK plug
Energy label according to EU Regulation 2019/2013
8 sets Flushmount Brackets 48 pcs Screws
Options / Peripherals / Upgrades
Elo Remote OSD (RJ45) – Elo P/N: E483757
Optional PCAP Stylus Pen – Elo P/N: E066148
Elo Backpack® 4 (Value Model)- Elo P/N: E393754
Elo Backpack® 4 (Standard Model) – Elo P/N: E393359
